Insulated buffer tank Puffer OILON 1600 Cordivari

Insulated buffer tank from Italian manufacturer Cordivari. Option to add a domestic hot water heat exchanger.

• Soft removable Nofire polyester fleece 100% high thermal insulation insulation made from recycled material – in compliance with ErP2017 regulation 2009/125/C
• All buffer tank nozzles have 2” threads. In addition, 3/4” thermometer sockets
• Maximum temperature: 99 °C
• Maximum pressure: 6 bar
• Energy class: C
• NB! Copper coil heat exchanger is not included in the tank price

Suitable copper coil heat exchangers:

•  3,17m2 (V=2,51L) Ø190mm L=665mm with 1” flange (includes 1″ – 3/4″ adapter) LK45 Cordivari
•  4,54m2 (V=3,6L) Ø190mm L=750mm with 1¼ flange LK60 Cordivari
• 6,34m2 (V=5,1L) Ø190mm L=980mm with 1¼ flange LK80 Cordivari
