Kalvis K-4 Water-Jacketed Stove

Product code: xx-172

2 056,00

ESTO 3
ESTO järelmaks

The Kalvis K-4 central heating stove can be connected to radiators, underfloor heating, and a domestic hot water boiler. The set includes a combustion air regulator that automatically maintains the set temperature of the hot water leaving the stove. Heated area: 80-160 m²



  • Suitable for heating rooms and preparing food
  • High efficiency
  • Large firebox capacity
  • Large water jacket capacity
  • Combustion air regulator included
  • Ignition damper
  • Fire grate in lower and upper position
  • Flue gas temperature: 210ºC
  • Minimum chimney draft: 15 Pa



The stove is manufactured in Lithuania and is well suited for heating Nordic living spaces.



SKU: xx-172 Categories: , , Tag:

Description

The stove also has a space for an electric heating element, which can be purchased separately. The electric heating element makes it possible to leave home for a while even in severe cold, while maintaining + degrees so that the heating system does not freeze and burst.

The stove has a spacious firebox and water jacket, so heat transfer happens quickly.
The stove top plate has a water jacket, and in the middle there is a single cooking plate with cast-iron rings; only the ring section heats up, preventing overheating of the room where the stove is located.
The fire grate can also be raised to the upper position.

Mandatory additional equipment to prevent overpressure includes a 1.5 bar safety valve, expansion tank, and circulation pump (a pump is not needed when connected by gravity flow).
The flue outlet is located at the top of the back wall, diameter 160mm.

Kalvis K-4 Water-Jacketed Stove Kütteseadmed Sanitaartehnika Soojuspumbad Puidukatlad Korstnad Radiaatorid Boilerid Torud Tarvikud

Kalvis K-4 Water-Jacketed Stove Kütteseadmed Sanitaartehnika Soojuspumbad Puidukatlad Korstnad Radiaatorid Boilerid Torud Tarvikud

General
Manufacturer Blacksmith
Weight (kg) 224
Measurements
Height (mm) 940
Width (mm) 1090
Depth (mm) 560
Smoke pipe diameter (mm) 160
Tree length (mm) 400
Power/currents
Power (kW) 14
Benefits
Efficiency (%) 76
Volumes/pressures
Volume (L) 63
