Thermostatic Mixing Valve Hydromix 35-65°C 1” Male Thread LK Armatur (KVS 1.6)

Thermostatic mixing valve for domestic water DN25 (1″), with thermostat +35 – +65°C Kvs 1.6 brass, male threads, LK 551 HydroMix.

Operating temperature: min +5 °C / max +95 °C
Max. operating pressure: 1.0 MPa (10 bar)

1. Water – ethylene glycol mixture max. 50%
2. Water – propylene glycol mixture max. 50%
3. Water – ethanol mixture max. 50%
Weight: 0.5 kg
Material, valve body: DZR brass EN 12165 CW626N
Temperature stability: ± 3 °C
Manufacturer: LK Armatur AB
